Hubble Cloudlink

Hubble Cloudlink

Hubble Cloudlink

Regular price R 3,470.00 incl. VAT Sale price R 3,213.00 incl. VAT Save R 257
R 2,79391 excl. VAT
incl. VAT /


Tax included. Shipping calculated at checkout.
  • Secure online payments

Product Description

The Hubble Cloudlink is an optional add-on to the Hubble X and AM range of products. As long as the device is connected to Wi-Fi it will store all battery and inverter data to our cloud-server enabling users to remotely monitor their power system.

The Hubble Cloudlink connects to the Hubble BMS battery through the BMS RS232 port, which enables the device to integrate directly with our BMS and report all statistics and alarms to the cloud for remote monitoring of both the batteries and select inverters.

Additionally the Hubble Cloudlink has its own Can Bus protocol. This protocol encapsulates 5 different CAN Bus protocols. When you connect the Cloudlink device to a CAN Bus enabled Inverter, the Hubble Cloudlink will automatically detect the correct CAN Bus protocol to use through it's  A.I. (Artificial Intelligence) technology and then enable the best protocol for your inverter.​

Features:

  • A.I. - Artificial Intelligence Processor
  • CAN bus converter for Hubble Lithium BMS
  • Cloud monitoring of batteries and select inverters
  • Engineered, designed & assembled in South Africa
  • Reports inverter values to the cloud for monitoring
  • Smart 1Phase & 3Phase meter ready for Cloud Monitoring
  • RS232, CAN bus, 3G, RS485 Modbus communication ports
  • Industry grade encrypted communications & cloud reporting
  • Easy install - “Plug & Play” power over RS232 for select inverters
  • Embedded Protocols: Hubble Cloudlink, Victron, SMA, Pylontech
  • Multiple CAN bus protocols built in for maximum inverter compatibility

Technical specifications:

  • Input Voltage: 20V to 75V DC
  • Input Power: <2W
  • Mode Button: Multi function button for: Config. mode, factory reset
  • Compatible Batteries: AM Series & X Series

Compatible Inverters:

 Axpert Inverter Models with Full Monitoring & Remote Control:

  • MKS HV 24V 5KVA
  • KS HV 24V 5KVA
  • MKS HV 48V4K/5KVA
  • KS HV 48V 4/5KVA
  • MKS 4/5KVA
  • KS 4/5KVA
  • ALFA M-5000
  • ALFA P-5000
  • Plus Duo/Tri 5KVA
  • EPS 5KVA
  • EPS M5K E
  • EPS 3/3 5KW
  • MKS II 5KW
  • KING 5KW
  • KING 3KW
  • MKS II 5KW Phocos
  • MLV 5KW
  • VMIII
  • VP-5000
  • VM-5000
  • VP-3000
  • VM-3000
  • MKS+- 2000-48
  • MLV 3KVA
  • PLV 3KVA
  • MKS HV 24V 5KVA
  • KS HV 24V 3KVA
  • VMIII
  • MKS II 5KW
  • MKS II 5KW LV
  • SE 3.5K
  • SE 5.5K
  • MKS III 5KW
  • 6K
  • 2K
  • MAX5K LV
  • VMIII 3.2KW GTI
  • VMII
  • VMII Fusion GTI
  • MKS II 5KW
  • MKS Zero LV 0.7KW
  • MKS Zero LV 1.4KW
  • MKS Zero LV 2.6KW
  • KING 5KW
  • KING 3KW

Other Inverter Models:

  • DEYE
  • SUNSYNK

Please Note:  Full monitoring is only available for the 8KW inverters currently, but will expand to the 5KW inverters

Communications:

  • CAN Bus : CAN
  • MOD Bus: RS485
  • Serial: RS232

Wi-Fi Mode:

  • Wi-Fi Mode: Station/SoftAP/SoftAP=Station/P2P
  • Standards: FCC/CE/IC/TELEC/KCC/SRRC/NCC
  • Protocol: 802.11b/g/n/e/i (802.11n up to 150 Mbps)
  • Security: WPA/WPA2/WPA-2-Enterprise/WPS

Bluetooth:

  • Protocols: Bluetooth V4.2 BR/EDR & BLE Specification
  • Radio: NZIF receiver with -98 dBm sensitivity Class-1, Class-2 & Class-3 transmitter
  • Dimensions: 80mm x 75mm x 32mm

*Due to continuous product improvements specifications are subject to change without prior notice.



    Important:

    All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
