Features

• Up to 10 x batteries can be connected in a parallel configuration.
• 10-year local manufacturer’s warranty.
• Battery power cables come as standard with each battery.
• Intergrated DC breaker for battery isolation and over-current protection
• 80% DoD or 4000 cycles.
• 1C rated battery giving a total charge/discharge power of 100kW.

Technical Specifications

• Total Energy Capacity [kWh]: 100
• Energy, 80% DoD [kWh]: 80
• Energy, 90% DoD [kWh]: 90
• Current Capacity [Ah] 200
• Max/Cont. Charge and Discharge Current [A] 1 200/200
• Max & Cont. Charge and Discharge Power [kW] 112
• Nominal Voltage [V] 512
• Max/Min. Operating Voltage [V] 568/456
• Max Recommended Inverter Total Rated Power (cont.) [kVA] 120
• Short Circuit Current [kA] 5
• Battery Dimensions - H x W x D [mm] 2 1405x1636x365
• Crated Dimensions - H x W x D [mm] 1600x1790x575
• Battery Weight [kg] 800
• Crated Weight [kg] 914
• DC Connection – Fly Leads (no. per electrode) [mm²] 3 1x95mm² Permopower
• Round Trip Efficiency [%] 96-97

Enclosure -  3mm thick Aluminium, powder coated, tamper proof, indoor use, rated to IP20

Protection - Shunt Trip Circuit Breaker sized to suit max current, can be tripped by BMS if critical fault, manual reset. Protection for overcurrent, cell under and over voltage, temperature, weak cell detection and other critical events

Control Interface -  CAN Bus for diagnostics & troubleshooting. RJ45 Strictly for BMS & inverter communication

Human Interface - On and Off buttons, State of Charge display (0 to 100%), Error light, Error Reset button, USB plug for programming and data access with PC, main breaker

On-board Management - Full battery management system and internal trip protection

Battery Chemistry -  Lithium Iron Phosphate (LiFePO4)

Cell Form Factor -  Large Format heavy-duty prismatic cells of 200Ah each and 3.2V nominal voltage, fully sealed in aluminium casing with laser welded electrode connections

Battery Cooling - Natural convection (heat generation is negligible inside the battery) Fan and louver cooling solution

Suitable Ambient Temp [°C] -  4 0°C to +35°C

Extreme Operating Temp [°C] - -20°C to +60°C

Warranty - Standard Warranty: 10 years (or 6000 cycles) 80% DoD, 0.5C Max Discharge, 0.25C Max Charge, Max 25°C

Service Life - > e.g. 16 years (>5 500 cycles) expected life at 80% DoD per cycle, >20 years (>7 500 cycles) at 50% DoD
