Technical Specifications

• Input voltage range: Up to 18V per battery, 36V total.
• Turn on level: 27,3V +/- 1%.
• Turn off level: 26,6V +/- 1%.
• Current draw when off: 0,7 mA.
• Midpoint deviation to start balancing: 50 mV.
• Maximum balancing current: 0,7A (when deviation > 100 mV).
• Alarm trigger level: 200 mV.
• Alarm reset level: 140 mV.
• Alarm relay: 60V / 1A normally open.
• Alarm relay reset: Two terminals to connect a push button.
• Over temperature protection: Yes.
• Operating temperature: -30 t0 +50°C.
• Humidity (non-condensing): 95%.

Enclosure

• Colour: Blue (RAL 5012).
• Connection terminals: Screw terminals 6 mm² / AWG10.
• Protection category: IP22.
• Weight: 0,4 kg.
• Dimensions (h x w x d): 100 mm x 113 mm x 47 mm.
