- Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99% and freedom from electrolyte maintenance or water adding.
- Not restricted for air transport-complies with IATA/ICAO Special Provision A67.
- UL-recognized component.
- Can be mounted in any orientation.
- Computer designed lead, calcium tin alloy
- grid for high power density.
- Long service life, float or cyclic applications.
- Maintenance-free operation.
- Low self-discharge.
- Nominal Voltage: 12V.
- Number of cells: 6.
- Design life: 12 Years.
- Max. Discharge Current @ 25oC: 900A(5s).
- Short Circuit Current: 2100A.
- Internal Resistance (Fully Charged battery @ 25°C): 5.7mOhms.
- Self-Discharge: 3% of capacity declined per month @ 20°C(average).
Nominal Capacity @ 25°C
- 10-hour rate (10.0A, 10.8V) 100Ah.
- 5-hour rate (17.4A, 10.5V) 87.0Ah.
- 3-hour rate (26.6A, 10.5V) 79.8Ah.
- 1-hour rate (65.2A, 9.6V) 65.2Ah.
Operating Temperature Range
- Discharge: -20~60°C.
- Charge: -10~60°C
- Storage: -20~60°C.
Charge Methods (Constant Voltage Charge @ 25°C)
Cycle use: 2.40-2.45VPC
- Maximum charging current: 30A.
- Temperature compensation -30mV/°C.
Standby use 2.20-2.27VPC
- Temperature compensation -20mV/°C.
Dimensions and Weight
- Length(mm): 330.
- Width(mm): 171.
- Height(mm): 215.
- Total Height(mm): 220.
- Approx. Weight (Kg): 30.
Please Note: The above characteristics data are average values obtained within three charge/discharge cycles not the minimum values.
