Victron Quattro 15kVA 12kW 48V Inverter-Charger

Victron Quattro 15kVA 12kW 48V Inverter-Charger

Regular price R 103,826.00 incl. VAT Sale price R 76,908.00 incl. VATSave R 26,918
R 66,87652 excl. VAT
incl. VAT/


Tax included. Shipping calculated at checkout.
  • Secure online payments

Technical specifications
Inverter

  • Input voltage range (V DC): 9,5 – 17V, 19 – 33V, 38 – 66V.
  • Output voltage: 230 VAC ± 2%.
  • Output Frequency: 50 Hz ± 0,1%.
  • Cont. output power at 25°C (VA): 15 000.
  • Cont. output power at 25°C (W): 12 000.
  • Cont. output power at 40°C (W): 10 000.
  • Cont. output power at 65°C (W): 7000.
  • Peak power (W): 25 000.
  • Maximum efficiency (%): 96.
  • Zero load power (W) 80.
  • Zero load power in AES mode (W): 50.
  • Zero load power in Search mode (W): 50.

Charger

  • Charge voltage 'absorption' (V DC): 57,6.
  • Charge voltage 'float' (V DC): 55,2.
  • Storage mode (V DC): 52,8.
  • Charge current house battery (A): 200.
  • Charge current starter battery (A): 4 (12V and 24V models only).
  • Battery temperature sensor: Yes.

General

  • Power Control / Power Assist: Yes.
  • Integrated Transfer switch: Yes.
  • AC Input voltage range (x2): 187-265 VAC
  • Input frequency: 45 – 65 Hz.
  • Power factor: 1.
  • Maximum feed through current (A): 2 x 100.
  • Auxiliary output (A): 50.
  • Programmable relay: 3x.
  • VE. Bus communication port: For parallel and three phase operation, remote monitoring and system integration.
  • General purpose com. port: 2x.
  • Remote on-off: Yes.
  • Operating temp.: -40 to +65˚C.
  • Humidity (non-condensing): max. 95%.

Enclosure

  • Material & Colour: aluminium (blue RAL 5012).
  • Protection category: IP 21.
  • Battery-connection: Four M8 bolts (2 plus and 2 minus connections)
  • 230 V AC-connection: M6 Bolts.
  • Weight (kg): 72.
  • Dimensions (hxwxd in mm): 572 x 488 x 344.

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
