Product Overview
The Victron Phoenix VE.Direct 375VA 48V Schuko Inverter is a 48V inverter designed to supply 230V sinewave AC from a suitable battery system. It combines a 375VA inverter rating with VE.Direct communication and the Schuko outlet configuration.
Key Features
- 48V DC inverter model with a 375VA rating.
- 230V sinewave AC output.
- VE.Direct communication interface.
- Schuko outlet configuration.
- 86 x 165 x 260mm enclosure.
Applications
- Small 48V battery-based power systems.
- Supporting 230V loads sized within the 375VA inverter rating.
- Installations that use compatible VE.Direct monitoring or configuration equipment.
Why Choose This Product?
This model provides additional inverter capacity over a 250VA unit while retaining a compact 48V, VE.Direct and Schuko configuration.
Important Notes
- Installation must be completed by a qualified electrician or suitably qualified installer.
- Confirm the plug configuration, battery voltage and connected load requirements before purchase.
Technical Specifications
| Specification |
Detail |
| Brand |
Victron Energy |
| Model |
Inverter 48/375 VE.Direct Schuko |
| Product Code |
PIN481371200 |
| Product Type |
230V Sinewave Inverter |
| DC System Voltage |
48V |
| Rated Size |
375VA |
| AC Output |
230V |
| Communication |
VE.Direct |
| Outlet Configuration |
Schuko |
| Dimensions |
86 x 165 x 260mm |
| Weight |
3.0kg |
