Product Overview
The Victron Smart IP43 Charger 48/13(1) 120-240V is a 48V battery charger with a 13A rated charging current and a single battery connection. Designed for suitable battery installations, it offers adaptive charging and Bluetooth monitoring and configuration through VictronConnect.
Key Features
- 13A charging current with a 6.5A low-current mode.
- Built-in Bluetooth and VE.Direct for monitoring and programmable charging settings.
- Adaptive six-stage charging algorithm, with a three-stage algorithm for lithium batteries.
- Supports LiFePO4 charging when correctly configured for the battery system.
- Remote on/off, programmable relay and optional VE.Smart battery voltage and temperature sensing.
- Natural convection cooling and IP43 enclosure protection.
Applications
- Charging compatible 48V battery banks in stationary or mobile installations.
- Installations requiring programmable charging and remote monitoring.
- Suitable 48V battery maintenance applications.
Why Choose This Product?
The Smart IP43 combines configurable charging, battery monitoring and a compact aluminium enclosure. Its adaptive charging modes and connectivity provide practical control for installers and owners of appropriately configured 48V battery systems.
Important Notes
- This is the single-output 48/13(1) model; confirm battery chemistry, charging voltage and BMS requirements before installation.
- The AC mains cord must be ordered separately; the retainer clip is included.
- Rated output current applies up to 40 °C; charging current derates at higher ambient temperatures.
- Installation and electrical connections should be completed by a suitably qualified installer.
Technical Specifications
| Specification |
Detail |
| Brand |
Victron Energy |
| Model |
Smart IP43 Charger 48/13(1) 120-240V |
| Victron Code |
PSC481350095 |
| Product Type |
Battery charger |
| Battery Voltage |
48V |
| Charge Current |
13A |
| Low Current Mode |
6.5A |
| Number of Battery Connections |
1 |
| AC Input Voltage |
85–250V AC (full power from 100V AC) |
| Frequency |
45–65Hz |
| Maximum Efficiency (230V AC / 120V AC) |
96% / 94% |
| Charge Algorithm |
6-stage adaptive; 3-stage for Li-ion |
| Connectivity |
Bluetooth, VE.Direct |
| IP Rating |
IP43 |
| Operating Temperature |
-20 °C to 60 °C |
| Battery Connection |
Screw terminals, 16 sq.mm |
| AC Connection |
IEC 320 C14 inlet with retainer clip |
| Dimensions (H × W × D) |
180 × 249 × 116 mm |
| Weight |
2.7 kg |
