Victron Phoenix Smart IP43 24-16 16A 24V - 3 Output Battery Charger
Victron Phoenix Smart IP43 24-16 16A 24V - 3 Output Battery Charger

Victron Phoenix Smart IP43 24-16 16A 24V - 3 Output Battery Charger

Victron Phoenix Smart IP43 24-16 16A 24V - 3 Output Battery Charger

Regular price R 8,222.00 incl. VAT Sale price R 6,090.00 incl. VATSave R 2,132
R 5,29565 excl. VAT
incl. VAT/


Tax included. Shipping calculated at checkout.
  • Secure online payments

Product Description:

Victron Phoenix Smart IP43 24-16 16A 24V - 3 Output Battery Charger

Specifications:

  • Input voltage 230 VAC (range: 210 – 250 V)
  • DC input voltage range: 290 – 355 VDC
  • Frequency: 45-65 Hz
  • Power factor: 0.7
  • No load power consumption: 1 W
  • Efficiency: 94%
  • Charge voltage – Absorption / : Normal: 28.8 V / 27.6 V / 26.4 V
  • Float / Storage High: 29.4 V / 27.6 V / 26.4 V, Li-ion: 28.4 V / n/a / 27.0 V
  • Fully programmable: Yes, with Bluetooth and/or VE.Direct
  • Number of battery connections: (3) models: 3
  • Charge current house battery: 16 / 25 A
  • Low current mode: 8 / 12,5 A
  • Temperature compensation -32 mV/°C
  • Default
  • Charge current starter battery
  • Charge algorithm: 6-stage adaptive (3-stage for Li-ion):
  • Protection: Battery reverse polarity (fuse, not user accessible) / Output short circuit / Over temperature
  • Can be used as power supply: Yes, output voltage can be set with Bluetooth and/or VE.Direct
  • Operating temp. range: Humidity (non-condensing):-20 to 60 °C (0 – 140 °F) Rated output current up to 40 °C, derate linearly to 20 % at 60 °C
  • Remote on/off: Yes (2-pole terminal):max 95 %
  • Relay (programmable): DC rating: 5 A up to 28 VDC
  • Bluetooth: Power: -4 dBm | Frequency: 2402 – 2480 MHz
  • Material & Colour: aluminium (blue RAL 5012)
  • Battery-connection: Screw terminals 16 mm² (AWG6)
  • AC-connection: IEC 320 C14 inlet with retainer clip (AC cord with country specific plug must be ordered separately)
  • Protection category: IP43 (electronic components), IP22 (connection area)
  • Weight kg (lbs): 3,5 kg
  • Dimensions (hxwxd): 180 x 249 x 100 mm
  • Safety: EN 60335-1, EN 60335-2-29
  • Emission: EN 55014-1, EN 61000-6-3, EN 61000-3-2
  • Immunity: EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-3-3
  • Vibration: IEC68-2-6:10-150Hz/1.0G

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
