Victron Phoenix Smart 2kVA 2kW 12V-24V-48V Inverter

Victron Phoenix Smart 2kVA 2kW 12V-24V-48V Inverter

Regular price R 13,821.00 incl. VAT Sale price R 10,238.00 incl. VATSave R 3,583
R 8,90261 excl. VAT
incl. VAT/
Volts


Tax included. Shipping calculated at checkout.
  • Secure online payments

Features

  • Bluetooth built-in: fully configurable with a tablet or smartphone.
  • VE.Direct communication port.
  • Proven reliability.
  • High start-up power.
  • ECO mode.
  • Remote on/off.
  • LED diagnosis.
  • To transfer the load to another AC source: the automatic transfer switch.

Inverter

  • Input voltage range: 9.3 – 17V 18.6 – 34V 37.2 – 68V.
  • Output: Output voltage: 230 VAC ±2% 50 Hz or 60 Hz ± 0.1% (1).
  • Cont. output power at 25ºC (1): 2000 VA.
  • Cont. output power at 25ºC: 1600 W.
  • Cont. output power at 40ºC: 1450 W.
  • Cont. output power at 65ºC: 1000 W.
  • Peak power: 4000 W.
  • Max. efficiency 12V: 92 / 94 / 94%.
  • Zero load power 12V: 8 / 9 / 11 W.
  • Zero load power in ECO mode: 0.6 / 1.3 / 2.1 W.
  • General

  • Programmable relay (2) Yes: Yes.
  • Stop & start power ECO-mod: adjustable.
  • Protection (3): a - g.
  • Bluetooth wireless communication: For remote monitoring and system integration.
  • VE. Direct communication port: For remote monitoring and system integration.
  • Remote on-off: Yes.
  • Common Characteristics: Operating temperature range: -40 to +65ºC (fan assisted cooling).
  • Humidity (non-condensing): max 95%.
  • Enclosure
  • Common Characteristics: M8 bolts.
  • Battery-connection: Material & Colour: steel (blue RAL 5012; and black RAL 9017) Protection category: IP21.
  • 230 V AC-connection: Screw terminals.
  • Weight: 13kg.
  • Dimensions (hxwxd):485 x 219 x 125mm.
  • Important:

    All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
