Virtually unlimited power thanks to parallel and 3-phase operation capability.

Up to 6 units inverters can operate in parallel to achieve higher power output. Six 24/5000 units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

To transfer the load to another AC source: the automatic transfer switch.

If an automatic transfer switch is required we recommend using the MultiPlus inverter/charger instead. The switch is included in these products and the charger function of the MultiPlus can be disabled. Computers and other electronic equipment will continue to operate without disruption because the MultiPlus features a very short switchover time (less than 20 milliseconds).

Computer interface.

All models have a RS-485 port. All you need to connect to your PC is our MK2 interface (see under accessories).This interface takes care of galvanic isolation between the inverter and the computer, and converts from RS-485 to RS-232. A RS-232 to USB conversion cable is also available. Together with our VEConfigure software, which can be downloaded free of charge from our website, all parameters of the inverters can be customised. This includes output voltage and frequency, over and under
 voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to VENet, the new power control network of Victron Energy, or to other computerised monitoring and control systems.

New applications of high power inverters

The possibilities of paralleled high power inverters are truly amazing. For ideas, examples and battery capacity calculations  please  refer  to  our  book  “Energy  Unlimited”  (available  free  of  charge  from  Victron  Energy  and downloadable from www.victronenergy.com)

Techinical Specifications.

Parallel and 3-phase operation.

Yes

INVERTER

Input voltage range (V DC).

    * 9,5 – 17V

Output

    * Output voltage: 230 VAC ±2% Frequency: 50 Hz± 0,1% (1)
    * Cont. output power at 25ºC (VA)(2):1200
    * Cont. output power at 25ºC (W): 1000
    * Cont. output power at 40ºC (W): 900
    * Peak power (W): 2400
    * Max. efficiency 12/ 24 V (%): 92 / 94
    * Zero-load power 12 / 24 V (W): 8 / 10
    * Zero-load power in AES mode (W): 5 / 8
    * Zero-load power in Search mode (W): 2/3

GENERAL

    * Programmable relay (3): Yes
    * Protection (4): a - g
    *VE.Bus communication port: For parallel and three phase operation, remote monitoring and system integration
    *Remote on-off :Yes
    *Common Characteristics Operating temperature range: -40 to +50ºC (fan assisted cooling) Humidity (non condensing): max 95%

ENCLOSURE

    * Common Characteristics: Material & Colour: aluminum (blue RAL 5012)Protection category: IP 21
    * Battery-connection: battery cables of 1.5 meter included
    * 230 V AC-connection: G-ST18i plug
    * Weight (kg): 10
    * Dimensions (hxwhd in mm): 375x214x110
