Product Overview
The Victron MultiPlus-II 48/6k5/100-50 230V is a 48V inverter-charger designed for backup power, off-grid and energy storage applications. It combines a 6kW continuous inverter output at 25°C with a 100A battery charger and a 50A AC transfer capability, making it suitable for larger residential and professional power systems.
Key Features
- 6kW continuous output at 25°C with up to 11kW peak power for short-duration high-load demands.
- 100A battery charging capability at 25°C for efficient charging of suitably sized 48V battery banks.
- PowerControl and PowerAssist help manage limited grid or generator supply and supplement it with battery power when required.
- UPS functionality transfers to inverter power in less than 20 milliseconds during an AC supply interruption.
- Supports VE.Bus communication for system integration, remote monitoring and parallel or three-phase system configurations.
- Compatible with a range of supported battery chemistries when correctly configured for the installation.
Applications
- Residential backup power and energy storage systems.
- Off-grid homes, farms and remote installations.
- Commercial and professional systems requiring higher inverter and charger capacity.
- Generator-assisted systems where PowerAssist can help manage peak demand.
Why Choose This Product?
The MultiPlus-II combines inverter, charger and transfer-switch functionality in one platform, with Victron's established system integration options through VE.Bus and GX devices. The 48/6k5 model offers substantially more output and charging capacity than smaller MultiPlus-II models while retaining the same modular system approach.
Important Notes
- This is the non-GX MultiPlus-II 48/6k5/100-50 230V model, product code PMP482605012.
- Battery bank sizing, protection, cabling and system configuration must be designed for the required charge and discharge currents.
- Installation and commissioning should be carried out by a suitably qualified installer or electrician in accordance with applicable South African electrical requirements.
- Battery compatibility and configuration must be confirmed against the relevant Victron battery compatibility documentation and battery manufacturer's requirements before installation.
Technical Specifications
| Specification |
Detail |
| Brand |
Victron Energy |
| Model |
MultiPlus-II 48/6k5/100-50 230V |
| Product Code |
PMP482605012 |
| Product Type |
Inverter-Charger |
| Battery Voltage |
48V nominal |
| DC Input Voltage Range |
38-60V |
| AC Output Voltage |
230VAC ± 2% |
| AC Output Frequency |
50Hz ± 0.1% |
| Continuous Output Power at 25°C |
6kW |
| Continuous Output Power at 40°C |
5.7kW |
| Continuous Output Power at 65°C |
4.6kW |
| Peak Power |
11kW for 1 minute |
| Maximum Efficiency |
96% |
| Maximum Battery Charge Current at 25°C |
100A |
| Maximum Battery Charge Current at 40°C |
95A |
| Maximum AC Input Current |
50A |
| Maximum Feed-Through Current |
50A |
| AC Input Voltage Range |
187-265VAC |
| AC Input Frequency Range |
45-65Hz |
| Dimensions |
644 x 320 x 150mm |
| Weight |
30kg |
