- Input voltage range (V DC): 9.5-17V/ 19-33V/ 38-66V.
- Output: Output voltage: 230 VAC ± 2%; Frequency: 50 Hz ± 0,1%.
- Cont. output power at 25°C (VA): 800.
- Cont. output power at 25°C (W): 700.
- Cont. output power at 40°C (W): 650.
- Cont. output power at 65°C (W): 400.
- Peak power (W): 1600.
- Maximum efficiency (%): 92/94.
- Zero load power (W): 8/10.
- Zero load power in AES mode (W): 5/8.
- Zero load power in Search mode (W): 2/3.
- AC Input: Input voltage range: 187-265 VAC; Input frequency: 45 – 65 Hz; Power factor: 1.
- Charge voltage 'absorption' (V DC): 14.4/ 28.8/ 57.6.
- Charge voltage 'float' (V DC): 13.8/ 27.6 / 55.2.
- Storage mode (V DC): 13.2/ 26.4/ 52.8.
- Charge current house battery (A): 35/16.
- Charge current starter battery (A): 4 (12 V and 24 V models only).
- Battery temperature sensor: Yes.
- Power Control: Yes.
- Power Assist: Yes.
- Transfer switch (A): 16.
- Auxiliary output: N/A.
- Programmable relay: Yes.
- VE. Bus communication port: For parallel and three phase operation, remote monitoring and system integration.
- General purpose com. port: N/A.
- Remote on-off: Yes.
- Common Characteristics: Operating temp. range: -40 to +65°C (fan assisted cooling) Humidity (non-condensing): max 95%.
- Material & Colour: aluminium (blue RAL 5012).
- Protection category: IP 21.
- Battery-connection: battery cables of 1.5 meter.
- 230 V AC-connection: G-ST18i connector.
- Weight (kg): 10
- Dimensions (hxwxd)(mm): 375 x 214 x 110.
