Technical Specifications
Inverter
- Input voltage range (V DC): 9.5-17V/ 19-33V/ 38-66V.
- Output: Output voltage: 230 VAC ± 2%; Frequency: 50 Hz ± 0,1%.
- Cont. output power at 25°C (VA): 1600.
- Cont. output power at 25°C (W): 1300.
- Cont. output power at 40°C (W): 1250.
- Cont. output power at 65°C (W): 800.
- Peak power (W): 3000.
- Maximum efficiency (%): 92/94.
- Zero load power (W): 8/10.
- Zero load power in AES mode (W): 5/8.
- Zero load power in Search mode (W): 2/3.
Charger
- AC Input: Input voltage range: 187-265 VAC; Input frequency: 45 – 65 Hz; Power factor: 1.
- Charge voltage 'absorption' (V DC): 14.4/ 28.8/ 57.6.
- Charge voltage 'float' (V DC): 13.8/ 27.6 / 55.2.
- Storage mode (V DC): 13.2/ 26.4/ 52.8.
- Charge current house battery (A): 70/40.
- Charge current starter battery (A): 4 (12 V and 24 V models only).
- Battery temperature sensor: Yes.
General
- Power Control: Yes.
- Power Assist: Yes.
- Transfer switch (A): 16.
- Auxiliary output: N/A.
- Programmable relay: Yes.
- VE. Bus communication port: For parallel and three phase operation, remote monitoring and system integration.
- General purpose com. port: N/A.
- Remote on-off: Yes.
- Common Characteristics: Operating temp. range: -40 to +65°C (fan assisted cooling) Humidity (non-condensing): max 95%.
Enclosure
- Material & Colour: aluminium (blue RAL 5012).
- Protection category: IP 21.
- Battery-connection: battery cables of 1.5 meter.
- 230 V AC-connection: G-ST18i connector.
- Weight (kg): 10
- Dimensions (hxwxd)(mm): 375 x 214 x 110.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
