Technical Specifications
Inverter

• Input voltage range (V DC): 9.5-17V/ 19-33V/ 38-66V.
• Output: Output voltage: 230 VAC ± 2%; Frequency: 50 Hz ± 0,1%.
• Cont. output power at 25°C (VA): 5000.
• Cont. output power at 25°C (W): 4000.
• Cont. output power at 40°C (W): 3700.
• Cont. output power at 65°C (W): 3000.
• Peak power (W): 10 000.
• Maximum efficiency (%): 94/95.
• Zero load power (W): 30/35.
• Zero load power in AES mode (W): 25/30.
• Zero load power in Search mode (W): 10/15.

Charger

• AC Input: Input voltage range: 187-265 VAC; Input frequency: 45 – 65 Hz; Power factor: 1.
• Charge voltage 'absorption' (V DC): 14.4/ 28.8/ 57.6.
• Charge voltage 'float' (V DC): 13.8/ 27.6 / 55.2.
• Storage mode (V DC): 13.2/ 26.4/ 52.8.
• Charge current house battery (A): 120/70.
• Charge current starter battery (A): 4 (12 V and 24 V models only).
• Battery temperature sensor: Yes.

General

• Power Control: Yes.
• Power Assist: Yes.
• Transfer switch (A): 100.
• Auxiliary output: Yes (25A).
• Programmable relay: Yes.
• VE. Bus communication port: For parallel and three phase operation, remote monitoring and system integration.
• General purpose com. port: Yes.
• Remote on-off: Yes.
• Common Characteristics: Operating temp. range: -40 to +65°C (fan assisted cooling) Humidity (non-condensing): max 95%.

Enclosure

• Material & Colour: aluminium (blue RAL 5012).
• Protection category: IP 21.
• Battery-connection: Four M8 Bolts (2 positive and 2 negative connections).
• 230 V AC-connection: Screw terminals 13mm² (6AWG).
• Weight (kg): 30
• Dimensions (hxwxd)(mm): 444 x 328 x 240.
