Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger
Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger
Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger
Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger
Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger
Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger

Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger

Victron MultiPlus 2kVA 1.6kW 12V-24V Inverter-Charger

Regular price R 22,062.00 incl. VAT Sale price R 15,686.95 incl. VATSave R 6,375.05
R 13,64083 excl. VAT
incl. VAT/
Volts


Tax included. Shipping calculated at checkout.
  • Secure online payments

Features

  • Multifunctional, with intelligent power management.
  • Parallel operation and three phase capabilities.
  • PowerAssist - Boosting the capacity of shore or generator power.
  • Search Mode.
  • Programmable relay.
  • On-site system configuring, monitoring and control.
  • Remote configuring and monitoring with GX Products.

Technical Specifications

  • PowerControl / PowerAssist: Yes.
  • Three Phase and parallel operation: Yes.
  • Transfer switch: 35A.

Inverter

  • Input voltage range: 9,5V-17V / 19V-33V.
  • Output voltage: 230VAC ± 2%.
  • Frequency: 50Hz ± 0,1%.
  • Cont. output power at 25°C (3): 2000VA.
  • Cont. output power at 25°C: 1600W.
  • Cont. output power at 40°C: 1400W.
  • Cont. output power at 65°C: 1000W.
  • Peak power: 3500W.
  • Maximum efficiency: 93% / 94%.
  • Zero-load power: 10W / 9W / 10W.
  • Zero-load power in search mode: 3W.

Charger

  • AC Input voltage range: 187VAC - 265VAC.
  • Input frequency: 45 Hz – 65 Hz.
  • Charge voltage 'absorption': 14,4V / 28,8V.
  • Charge voltage 'float': 13,8V / 27,6V.
  • Storage mode: 13,2V / 26,4V.
  • Charge current house battery: 80A / 50A.
  • Charge current starter battery: 1A (12V and 24V models only)
  • Battery temperature sensor: Yes.

General

  • Programmable relay: Yes.
  • Protection: (2) a ; g (Please see specifications sheet).
  • VE.Bus communication port: For parallel and three phase operation, remote monitoring and system integration (RJ45-spliter ASS030065510 needed for 500 / 800 / 12oo VA models)
  • Remote on-off: On/off.
  • DIP switches: Yes (7).
  • Internal DC fuse: No.
  • Common Characteristics Operating temp. range: -40 to +65°C (fan assisted cooling) Humidity (non-condensing): max 95%
  • 5 year warranty.

Enclosure

  • Material & Colour: Steel (blue RAL 5012).
  • Protection category: IP 22.
  • Battery-connection: M8 bolts.
  • 230V AC-connection: Screw.
  • Weight: 13.5 kg.
  • Dimensions (h x w x d): 500 mm x 225 mm x 135 mm.

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
