Features

• Multifunctional, with intelligent power management.
• Parallel operation and three phase capabilities.
• PowerAssist - Boosting the capacity of shore or generator power.
• Search Mode.
• Programmable relay.
• On-site system configuring, monitoring and control.
• Remote configuring and monitoring with GX Products.

Technical Specifications

• PowerControl / PowerAssist: Yes.
• Three Phase and parallel operation: Yes.
• Transfer switch: 16A.

Inverter

• Input voltage range: 9,5V-17V / 19V-33V / 38V-66V.
• Output voltage: 230VAC ± 2%.
• Frequency: 50Hz ± 0,1%.
• Cont. output power at 25°C (3): 1600VA.
• Cont. output power at 25°C: 1300W.
• Cont. output power at 40°C: 1100W.
• Cont. output power at 65°C: 800W.
• Peak power: 2800W.
• Maximum efficiency: 93% / 94% / 95%.
• Zero-load power: 10W / 9W / 10W.
• Zero-load power in search mode: 3W.

Charger

• AC Input voltage range: 187VAC - 265VAC.
• Input frequency: 45 Hz – 65 Hz.
• Charge voltage 'absorption': 14,4V / 28,8V / 57,6V.
• Charge voltage 'float': 13,8V / 27,6V / 55,2V.
• Storage mode: 13,2V / 26,4V / 52,8V.
• Charge current house battery: 70A / 40A / 20A.
• Charge current starter battery: 1A (12V and 24V models only)
• Battery temperature sensor: Yes.

General

• Programmable relay: Yes.
• Protection: (2) a ; g (Please see specifications sheet).
• VE.Bus communication port: For parallel and three phase operation, remote monitoring and system integration (RJ45-spliter ASS030065510 needed for 500 / 800 / 12oo VA models)
• Remote on-off: On/off.
• DIP switches: Yes (7).
• Internal DC fuse: 200 / 125 / 60 A.
• Common Characteristics Operating temp. range: -40 to +65°C (fan assisted cooling) Humidity (non-condensing): max 95%
• 5 year warranty.

Enclosure

• Material & Colour: Steel/ABS (blue RAL 5012).
• Protection category: IP 21.
• Battery-connection: 50 / 35 / 16 mm².
• 230V AC-connection: G-ST18i connector.
• Weight: 10,2 kg.
• Dimensions (h x w x d): 470 mm x 265 mm x 120 mm.
