- Quality without compromise.
- Universal 90-265V AC input voltage range and also suitable for DC supply (AC-DC and DC-DC operation)
- Three outputs that can each supply the full output current
- Three-stage charging, with temperature compensation
- Learn more about batteries and battery charging
- Also charges Li-ion (LiFePO₄) batteries.
Blue Smart IP67 - 24/12 Specifications
- Input voltage range and frequency: 90-265 VAC; 45-65 Hz.
- Charge voltage 'absorption': Normal: 14.3V, High: 28,5.
- Charge voltage 'float': Normal: 13.5V, High: 27.0
- Charge voltage ‘storage’: Normal: 26,4V, High: 26,4V, Li-ion: 27,0V.
- Charge current, normal mode: 12/60.
- Charge current, LOW: 24/30.
- Can be used as power supply: yes.
- Protection: Output short circuit, Over temperature.
- Operating temp. range: -20 to +60°C (full rated output up to 40°C) Derate 3% per °C above 40°C.
- Humidity (non condensing):MAX 95%.
- Dimensions (h x w x d in mm): 426 x 239 x 135.
- Weight (kg): 5
- Protection Category: IP20.
- 5 year warranty.
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
