Features
- Quality without compromise.
- Universal 90-265V AC input voltage range and also suitable for DC supply (AC-DC and DC-DC operation)
- Three outputs that can each supply the full output current
- Three-stage charging, with temperature compensation
- Learn more about batteries and battery charging
- Also charges Li-ion (LiFePOâ‚„) batteries.
Specifications
- Input voltage(V AC) 90-265Â
- Input Voltage(V DC): 90-400
- Input frequency: 45-65 Hz.
- Charge voltage 'absorption': Normal: 14.3V, High: 28,5.
- Charge voltage 'float': Normal: 13.5V, High:Â 27.0
-
Output Banks: 3
- Charge current(A0 (2): 100/60.
- Ignition protected: yes.
- Recommended Battery capacity (Ah): 400-1000
- Protection: Output short circuit, Over temperature.
- Operating temp. range: -20 to +60°CÂ
- Humidity (non condensing): MAX 95%.
- Dimensions (h x w x d in mm): 514 x 252 x 123.
- Weight (kg): 12
- Protection Category: IP20.
- 5 year warranty.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
