- Ultra-fast Maximum Power Point Tracking (MPPT).
- Advanced Maximum Power Point Detection in case of partial shading conditions.
- Outstanding conversion efficiency.
- Flexible charge algorithm.
- Extensive electronic protection.
- Internal temperature sensor.
- Real-time data display options.
- Battery voltage: 12V/24V/48V Auto Select (software tool needed to select 36V).
- Rated charge current: 35A.
- Maximum PV power, 12V: 500W, 24V: 1000W, 36V:1500W, 48V: 4900W.
- Max. PV short circuit current: 40A.
- Maximum PV open circuit voltage: 150V absolute maximum coldest conditions. 245V start-up and operating maximum.
- Maximum efficiency: 98%.
- Self-consumption: Less than 10mA.
- Charge voltage 'absorption': Default setting: 14,4V/28,8V/43,2V/57,6V (adjustable with: rotary switch, display, VE. Direct or Bluetooth).
- Charge voltage 'float': Default setting - 13,8V/27,6V/41,4V/55,2V (adjustable: rotary switch, display, VE. Direct or Bluetooth).
- Charge algorithm: multi-stage adaptive.
- Temperature compensation: -16 mV / -32 mV / -68 mV / °C.
- Protection: Battery reverse polarity (fuse, not user accessible) / PV reverse polarity / Output short circuit / Over temperature.
- Operating temperature: -30 to +60°C (full rated output up to 40°C).
- Humidity: 95%, non-condensing.
- Dimensions (TR Version): 130 mm x 186 mm x 70 mm.
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
