SonX 200Ah 12V AGM Battery

SonX 200Ah 12V AGM Battery

Regular price R 7,820.00 incl. VAT Sale price R 6,015.00 incl. VATSave R 1,805
R 5,23043 excl. VAT
incl. VAT/


Tax included. Shipping calculated at checkout.
  • Secure online payments

RA12-200D is an AGM deep-cycle battery with 10 years floating design life, specially designed for frequent cyclic discharge use. By using thick grid & specific paste plates the battery has 30% more cyclic life time than standby batteries. Applications include solar & wind energy systems, golf carts, electric wheelchairs, etc.

Technical Specifications

  • Cells Per Unit: 6
  • Voltage Per Unit: 12
  • Capacity: 200Ah @10hr-rate to 1.80V per cell @25°C
  • Weight: Approx. 60.0 Kg (Tolerance ±1.5%)
  • Max. Discharge Current: 2000 A (5 sec)
  • Internal Resistance: Approx. 4 mΩ
  • Operating Temperature Range: Discharge: -20°C~60°C, Charge: 0°C~50°C, Storage: -20°C~60°C
  • Normal Operating Temperature Range: 25°C±5°C
  • Float charging Voltage: 13.6 to 13.8 VDC/unit Average at 25°C
  • Recommended Maximum Charging Current Limit: 60 A
  • Equalization and Cycle Service: 14.6 to 14.8 VDC/unit Average at 25°C
  • Self Discharge: RITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for more than 6 months at 25°C. Self-discharge ratio less than 3% per month at 25°C. Please charge batteries before using.
  • Terminal: Terminal F16
  • Container Material: A.B.S. UL94-HB, UL94-V0 Optional.
  • Dimensions: Unit: mm, Dimension: 522(L)x240(W)x219(H)

Warranty: 1 year sliding scale warranty (warranty dependent on Inverter and installation type). Please note the warranty does not cover installations where Axpert/Mecer/Synapse are used, if installed with these inverters the warranty will be void.

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
