Technical Specifications

• Cells Per Unit: 6.
• Voltage Per Unit: 12.
• Nominal Capacity: 100Ah @ 20hour-rate to 1.8V per cell @ 25°C.
• Weight: 30Kg.
• Max. Discharge Current: 1000A (5 sec).
• Internal Resistance: 5 mΩ.
• Terminal: F5/F12.
• Recommended Maximum Charging Current: 30A.
• Design Life: up to 12 years (Float charging).
• Self-Discharge: RITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for up to 6 months at 25°C and then recharging is recommended. Monthly Self-discharge ratio is less than 3% at 25°C.Please charge batteries before using.
• Normal Operating Temperature Range: 25C±5°C.
• Dimensions: (LxWxH): 328mm x 172mm x 222mm.
