Onesto 6A 1000V 10x38 DC Cylindrical Fuse
PVCF10 gPV solar fuse has 1,000VDC and 1 to 25A rated voltage and current, and 25kA rated breaking capacity. The 10mm x 38mm unit conforms to IEC/EN 60269-6 and TÜV.
Applications
- PV DC combiner boxes.
- Inverters and solar applications etc.
Specifications
- Model: PVCF10-6.
- Max Rated Voltage: 1000VDC.
- Max Amps: 6A.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
