A more significant limitation capability of short circuit current

• The limitation capability of a MCB is an internal characteristic which makes it possible to open the circuit before the short circuit current reaches its prospective maximum value.

A MCB with a better current limitation capability provides several advantages

• To reduce the thermal effects in the cable i.e increase life span of cables.
• To reduce the mechanical effects and electrodynamics forces on the different contacts.
• To reduce the electromagnetic effects which can be harmful to sensitive equipment / loads.

Technical Information

• Type: 2Pole.
• Rated current : 100 A.
• Curve : C.
• Rated short circuit breaking capacity : 6 kA.
• Rated service short circuit breaking capacity according to NF EN 60898 : 6 kA.
• Frequency : 50/60 Hz.
• Rated operational AC voltage : 230V /400V.
• Operating temperature : -25 to 60 °C.
