Features
- A 92-precent high-efficiency 48V industrial battery charger.
- Wide-range input voltages from 100-240VAC, 50-60Hz.
- Charges lead-acid and lithium-ion batteries up to 425 amp-hours.
- Integrated inhibit and remote LED functions.
- Converts to a power supply for zero voltage charging.
- Progressive repair method for sulfated batteries.
- Spark-proof technology and reverse polarity protection.
- Advanced diagnostics indication for damaged batteries.
- Designed for rugged environments and rated at IP66.
Technical Specifications
- Input Voltage AC: 110-120 VAC, 50-60Hz.
- Working Voltage AC: 85-130 VAC, 50-60Hz
- Efficiency: 85% Approx.
- Power: 443W Max
- Low-Voltage Detection: 2V (12V), 2V (16V),14V (24V).
- Back Current Drain: <5mA.
- Ambient Temperature: 0°C to +40°C.
- Charger Type: 8 Step, Smart Charger.
- Type of Batteries: 12V, 16V & 24V.
- Battery Chemistries: Wet, Gel, MF, CA, EFB, AGM, LIB.
- Battery Capacity: 50-550Ah (12V), 25-250Ah (24V), Maintains All Battery Sizes.
- Housing Protection: IP44.
- Cooling: Natural Convection.
- Dimensions (LxWxH): 26.7cm x 6.4cm x 4.1cm.
- Weight: 2.31 kg.
What’s in The Box
- G26000 Smart Charger.
- Battery Clamp Connectors with Integrated Eyelets.
- User Guide and Information Guide & Warranty.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
