Features

• Li-Ion Compatible.
• Output power from 8kW.
• LCD display and low idle current.
• High surge capacity for motor start.
• Timed overload capacity with auto shutdown.
• 3-Attempt auto restart with short circuit protection.
• Built in, high rate, two-stage battery charger.
• Minimum local service turnaround time.
• 5-year warranty.
• Fan cooling for optimum performance and component longevity.
• Audible buzzer indicating faults, overload and status.
• Available with a Comms Module for Wi-Fi access.
• Inverter Output power is de-rated at high ambient temperature.

Specifications - 8000W.
DC Input

• Nominal Voltage (VDC): 48.
• Max Input Amps: 200.
• Standby Power: 90W.

AC Output

• Voltage (VAC): 230V.
• Amps (A): 90A.
• Voltage Regulation: <3% RMS for entire battery voltage range.
• Frequency: 50Hz.
• Frequency Regulation: ±0.1Hz.
• Power factor: 1.
• Wave form: Pure Sine Wave.
• Peak Efficiency: 94%.
• Protection: Hardware Protection - Circuit Breaker, Overload Protection - Programmable Overload, Levels and Auto Retry.

Charger

• Float Voltage (VDC): 55.2.
• Maximum Current (A): 80.
• Boost Time: Selectable 1,2 or 3 hours.
