Main Specifications

• Dimming Interface: Triac / ELV.
• Input Voltage Range: 200 - 240 Vac ± 10%.
• Frequency: 50/60Hz.
• Input Current: 230Vac≤0.8 A.
• Efficiency: ≥ 85%.
• Inrush Current(typ.): Cold start 50 A at 230 Vac.
• Leakage Current: (I/P-O/P) <0.5 mA/230 Vac.
• Output Current: Max. 12.5 A.
• Output Voltage: 12Vdc.
• Output Voltage Range: 2Vdc ±0.5Vdc.
• Ripple & Noise: ≤200mV.
• Output Power: Max. 150W.
• Output Power Range: 1~150W.
• Overload Power Limitation: ≥102%~125%.
• Dimming Range: Max. 0.1~100%.
• Working Temperature.: tc: 85°C / ta: -30°C ~ 60°C.
• Working Humidity: 20 ~ 95%RH, non-condensing.
• Storage Temp., Humidity: -40 ~ 80°C, 10~95% RH.
• Temp. Coefficient: ±0.03%/°C(0-50°C).
• Vibration: 10~500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes.
• Dimension: 273 mm × 57 mm × 37 mm(L×W×H).
• Weight: 605g±10g.
