Product Overview
The Hubble AM-5+ is a 5.12kWh, 51.2V lithium iron phosphate (LiFePO4) battery designed for residential and small-business solar, backup power and energy storage systems. Its 100Ah capacity, 1C charge and discharge capability, integrated Battery Management System and built-in Cloudlink monitoring provide a practical low-voltage storage option for compatible inverter systems.
Key Features
- 5.12kWh design capacity with a nominal voltage of 51.2V and rated capacity of 100Ah.
- 1C performance with up to 100A continuous charging and 100A continuous discharging current.
- Uses prismatic LiFePO4 cells for a long service life and stable battery chemistry.
- Built-in Cloudlink monitoring supports 24/7 system monitoring.
- Integrated Battery Management System includes voltage protection, current limiting and protection against over-charge, over-discharge and over-temperature.
- CAN-bus communication supports integration with compatible inverter brands.
- Wall-mountable steel enclosure with heavy-duty side handles for easier handling and installation.
- Parallel operation is supported for larger-capacity systems when installed and configured according to Hubble requirements.
- 10-year unlimited-cycle warranty subject to Hubble Energy warranty terms and conditions.
Applications
- Residential solar power systems requiring low-voltage lithium battery storage.
- Home and small-business backup power systems.
- Hybrid and off-grid installations using a compatible inverter and correctly designed battery bank.
Why Choose This Product?
The AM-5+ combines 5.12kWh of storage with 1C performance, integrated monitoring and a wall-mountable format. It is suited to customers who want a compact Hubble low-voltage battery with built-in communications and monitoring for a professionally installed solar or backup power system.
Important Notes
- Inverter compatibility must be confirmed against Hubble Energy's current inverter compatibility guidance before installation.
- Installation and commissioning should be completed by a suitably qualified solar or electrical installer in accordance with Hubble Energy requirements and applicable South African standards.
- The 10-year unlimited-cycle warranty is subject to Hubble Energy terms and conditions.
- Parallel configuration and communication requirements must follow the current Hubble installation manual.
Technical Specifications
| Specification |
Detail |
| Brand |
Hubble Energy |
| Model |
AM-5+ |
| Product Type |
Low-Voltage Lithium Battery |
| Battery Chemistry |
Prismatic LiFePO4 |
| Rated Capacity |
100Ah |
| Nominal Voltage |
51.2V |
| Design Capacity |
5.12kWh |
| Equalised Charge Voltage |
55.2V |
| Maximum Continuous Charge Current |
100A |
| Maximum Continuous Discharge Current |
100A |
| C Rating |
1C |
| Monitoring |
Built-in Cloudlink |
| Communication Ports |
CAN-bus, Battery Link Ports |
| Dimensions (W x D x H) |
500mm x 153mm x 600mm |
| Weight |
Approx. 53kg |
| Design Life |
Approx. 15 years |
| Certification |
CE, IEC, UN38.3 |
| Enclosure |
White bake lacquer steel case |
| Charging Temperature |
-10°C to +50°C |
| Humidity |
15% to 75% |
| Storage Temperature |
10°C to +50°C |
| Protection |
Electronic circuit breaker, BMS voltage protection, current limiting |
| Warranty |
10-year unlimited-cycle warranty, subject to terms and conditions |
