Atess Hps 30Kw Hybrid Inverter

ATESS HPS 30kW Hybrid Inverter

ATESS HPS 30kW Hybrid Inverter

Regular price R 177,475.00 incl. VAT Sale price R 141,979.95 incl. VATSave R 35,495.05
R 123,46083 excl. VAT
incl. VAT/


Tax included. Shipping calculated at checkout.
  • Secure online payments

Features

  • All in one hybrid inverter.
  • Programmable working mode.
  • Touchscreen LCD Quadruple capacity by paralleling 4 units.
  • Supports remote control of DG.
  • Seamless on/off grid transfer.
  • SA: NRS 097 certified and COCT Certified

AC (Grid-Connected)

  • Apparent power: 33kVA.
  • Rated power: 30kW.
  • Rated voltage: 400V.
  • Rated current: 43A.
  • Voltage Range: 360V - 440V.
  • Rated Frequency: 50/60Hz.
  • Frequency Range: 45~55/55~65Hz.
  • THDI: <3%.
  • PF: 0.8lagging~0.8leading.
  • AC Connection: 3/N/PE.
  • AC Input: 60kVA.

AC (Off-Grid)

  • Apparent power: 33kVA.
  • Rated power: 30kW.
  • Rated voltage: 400V.
  • Rated Current: 43A.
  • THDU: ≤2%linear.
  • Rated frequency: 50/60Hz.
  • Overload capability: 110%-10 mins, 120%-1 min.

DC (Battery and PV)

  • Max. PV open-circuit voltage: 1000VDC.
  • Max. PV power: 45kWp.
  • PV MPPT voltage range: 480V-800V DC.
  • Battery voltage range at Max. charge power: 450V-600V.
  • Battery voltage range: 352-600V.
  • Max. charge power: 45kWp.
  • Max. discharge power: 33kW.
  • Max. charge current: 100A.
  • Max. discharge current: 93A.

General Information

  • Protection degree: IP20.
  • Noise Emission: <65dB(A)@1m.
  • Operating Temperature: -25°C~+55°C.
  • Cooling: Forced-air.
  • Relative Humidity: 0-95% non-condensing.
  • Maximum Altitude: 6000m (derate over 3000m).
  • Dimensions (W/H/D): 700/1660/600mm.
  • Weight: 355kg.
  • Build-in Transformer: Yes.
  • Transfer between on/off grid: Automatic≤10ms.
  • Standby Consumption: <30W.

Communication

  • Display: Touch Screen.
  • Communication: RS485/CAN.

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
