The Sunsynk single-phase hybrid inverter is a versatile and efficient solution for managing power from multiple sources including solar, the main electrical grid, and generators. Designed for both residential and commercial use, it offers seamless integration and advanced features to ensure reliable energy management.

Product Features

• Maximum charging/discharging current: 250A
• Compatible with diesel generator energy storage
• Parallel operation: Supports up to 16 units (single-phase) or 15 units (three-phase)
• Separate outputs for essential and non-essential loads
• Remote monitoring and configuration capabilities
• Includes a 5-year warranty

Technical Specifications

• Weight: 36 kg
• Length: 0.87 m
• Rated Power: 12,000 W
• Minimum MPPT Voltage: 150 V
• Maximum MPPT Voltage: 425 V
• DC Startup Voltage: 125 V
• DC Shutdown Voltage: 124 V
• Maximum Input Voltage: 500 V
• Maximum DC Power: 18,000 W
• Maximum AC Power (5 min): 12,000 W
• Surge AC Power (1 sec): 24,000 W
• Maximum DC Current: 78 A
• Maximum DC Inputs: 3
• DC Fuses: Not included
• Connector Type: MC4
• Included Connectors: 12
• European Efficiency: 97.6%
• Transformer: None
• MPPT Trackers: 3
• Integrated DC Switch: Yes
• Warranty: 5 years
