This panel is engineered for durability and long-term reliability, offering excellent performance in low-light conditions and high-temperature environments. Its robust construction ensures resistance to harsh weather conditions, making it suitable for both rooftop and ground-mounted applications.
With strong efficiency, dependable output, and long-term warranty support, the 460W solar panel is an ideal solution for maximizing energy generation and reducing electricity costs.
Key Features
-
High Power Output (460W): Delivers strong energy production for efficient system design.
-
Monocrystalline Half-Cell Technology: Improves efficiency and reduces internal power losses.
-
Enhanced Low-Light Performance: Maintains stable output during cloudy and low-irradiance conditions.
-
Durable & Weather Resistant: Built to withstand wind, snow, and harsh environmental conditions.
-
Improved Temperature Coefficient: Ensures better performance in high-temperature climates.
-
High System Voltage Compatibility (1500V DC): Allows flexible and cost-effective system configurations.
-
Long Service Life: Designed for extended performance with minimal degradation.
-
Reliable Warranty Support: Backed by industry-standard product and performance warranties.
Technical Specifications
| Electrical Characteristics (STC) |
| Rated Power (Pmax) |
460 W |
| Open Circuit Voltage (Voc) |
39.70 V |
| Maximum Power Voltage (Vmp) |
33.17 V |
| Short Circuit Current (Isc) |
14.64 A |
| Maximum Power Current (Imp) |
13.87 A |
| Module Efficiency |
23.0% |
| Power Tolerance |
0 ~ +3 W |
| Mechanical Specifications |
| Cell Type |
Monocrystalline |
| Cell Configuration |
Half-Cell |
| Number of Cells |
108 (6 x 18) |
| Dimensions |
1762 × 1134 × 30 mm |
| Weight |
22 kg |
| Front Glass |
Tempered Glass |
| Frame |
Anodized Aluminium Alloy |
| Junction Box |
IP68 Rated |
| Connector |
MC4 Compatible |
| Operating Conditions |
| Maximum System Voltage |
1500 V DC |
| Operating Temperature |
-40°C to +70°C |
| Max Series Fuse Rating |
30 A |
| Maximum Static Load (Front) |
2400 Pa |
| Maximum Static Load (Back) |
5400 Pa |
| Temperature Coefficients |
| Temperature Coefficient (Pmax) |
-0.290% / °C |
| Temperature Coefficient (Voc) |
-0.250% / °C |
| Temperature Coefficient (Isc) |
+0.03% / °C |
| Warranty (Typical) |
| Product Warranty |
12 Years |
