Electrical Data STC

• Model: CS6W
• Nominal Max. Power (Pmax): 545 W
• Operating Voltage (Vmp): 41.5 V
• Operating Current (Imp): 13.14 A
• Open Circuit Voltage (Voc): 49.4 V
• Short Circuit Current (Isc): 13.95 A
• Module Efficiency: 21.3%
• Operating Temperature: -40°C to +85°C
• Max System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
• Module Fire Performance: TYPE 1 (UL 61730) or CLASS C (IEC 61730)
• Max Series Fuse Rating: 25 A
• Application Classification: Class A
• Power Tolerance: 0 ~ +10 W


Mechanical Specifications

• Cell Type: Mono-crystalline
• Cell Arrangement: 144
• Dimensions: 2261 × 1134 × 35 mm
• Weight: 27.8 kg
• Front Cover: 3.2 mm tempered glass
• Frame: Anodized aluminium alloy
• Junction Box: IP68, 3 bypass diodes
• Cable: 4 mm² (IEC), 12 AWG (UL)
• Cable Length: 410 mm (16.1 in) (+) / 290 mm (11.4 in) (−) or custom
• Connector Options: T4 series or MC4-EVO2


Electrical Data NMOT

• Model: CS6W
• Nominal Max. Power (Pmax): 409 W
• Operating Voltage (Vmp): 38.9 V
• Operating Current (Imp): 10.52 A
• Open Circuit Voltage (Voc): 46.7 V
• Short Circuit Current (Isc): 11.25 A


Please note that panel dimensions and specifications are subject to change. Please double check with us that they are correct at time of purchase.
