Mechanical Data
- Cell Type: Mon-crystalline
- Cell Arrangement: 144 [2 × (12 × 6)]
- Dimensions: 2108 × 1048 × 40 mm
- Weight: 24.3 kg
- Front Cover: 3.2 mm tempered glass
- Frame: Anodized aluminium alloy, crossbar enhanced
- Junction Box: IP68, 3 bypass diodes
- Cable: 4.0 mm² (IEC), 12 AWG (UL)
Electrical Data NMOT
- Model: CS3W-450MS
- Nominal Max. Power (Pmax): 338 W
- Operating Voltage (Vmp): 38.5 V
- Operating Current (Imp): 8.76 A
- Open Circuit Voltage (Voc): 46.4 V
- Short Circuit Current (Isc): 9.35 A
Electrical Data STC*
- Nominal Max. Power (Pmax): 450 W
- Operating Voltage (Vmp): 41.1V
- Operating Current (Imp): 10.96 A
- Open Circuit Voltage (Voc): 49.1 V
- Short Circuit Current (Isc): 11.60 A
- Module Efficiency: 20.4%
Environmental & Safety
- Operating Temperature: -40°C to +85°C
- Max System Voltage: 1500V (IEC/UL) or 1000V (IEC/UL)
- Module Fire Performance: TYPE 1 (UL 1703)
- Connector: T4 series, H4 UTX, or MC4-EV
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
