Product Overview
The GoodWe LV ES UniQ 8kW single-phase hybrid inverter is designed for larger residential solar and backup systems that need more solar input flexibility and stronger low-voltage battery performance. Built around a 48V battery platform, it combines high PV input capacity, strong backup capability and flexible system integration for homes with heavier loads and more advanced energy requirements.
Key Features
- 8kW single-phase hybrid inverter designed for larger residential PV and energy storage systems.
- Compatible with 48V Li-Ion and lead-acid battery systems.
- Up to 16kW PV input capacity supports larger array designs with up to 200% PV oversizing.
- 2 MPPTs improve design flexibility across different roof orientations and string layouts.
- Up to 160A continuous charging and discharging current supports stronger battery throughput.
- Seamless switching to backup in under 4ms helps keep essential loads supplied during outages.
- 3-in-1 port supports generator input, smart loads and on-grid inverter integration.
- Supports on-grid and off-grid parallel operation of up to 6 units for scalable installations.
Applications
- Larger residential solar and battery systems.
- Homes with higher daily consumption and stronger backup requirements.
- Installations needing additional PV design flexibility across multiple roof sections.
- Projects planning for future expansion through parallel inverter operation.
Why Choose This Product?
The LV ES UniQ 8kW is a strong choice for households that need more output capacity and more PV flexibility than the 5kW and 6kW models. Its dual-MPPT layout, higher battery current capability and broader solar input capacity make it well suited to larger single-phase residential systems.
Important Notes
- Installation should be completed by a qualified electrician or solar installer.
- Battery compatibility should be confirmed against the latest approved GoodWe battery list before publishing or installation.
- AFCI and rapid shutdown functions are listed as optional features and may depend on the final configuration.
Technical Specifications
| Specification |
Detail |
| Brand |
GoodWe |
| Model |
GW8000-ES-C10 |
| Product Type |
Single-phase hybrid inverter (LV) |
| Nominal Output Power |
8.0kW |
| Max. PV Input Power |
16.0kW |
| Battery Type |
Li-Ion / Lead-acid |
| Nominal Battery Voltage |
48V |
| Battery Voltage Range |
40 - 60V |
| Max. Continuous Charging Current |
160A |
| Max. Continuous Discharging Current |
160A |
| Max. Charging Power |
8.0kW |
| Max. Discharging Power |
8.8kW |
| MPPT Trackers |
2 |
| Max. Input Current per MPPT |
32A / 16A |
| Max. Input Voltage |
600V |
| MPPT Operating Voltage Range |
60 - 550V |
| Max. Apparent Power Output to Utility Grid |
8.8kVA |
| Back-up Nominal Apparent Power |
8.0kVA |
| Max. Efficiency |
97.6% |
| Battery to AC Efficiency |
95.5% |
| Ingress Protection Rating |
IP66 |
| Cooling Method |
Smart fan cooling |
| Dimensions |
560 × 444.5 × 226mm |
| Weight |
27.0kg |
| Mounting Method |
Wall mounted |
| Communication with BMS |
CAN |
