Multi Contact MC4 Cable Coupler Pack
Features
- Snap-in lock.
- Locking by safety lock clip PV-SSH4 in accordance with NEC 2011, can be released only with tool.
- Proven MULTILAM technology with high long-term stability, which ensures consistently low performance loss throughout the entire service life of the plug connector.
- Tried and tested plug connectors, 14 years of experience in the field.
- Available for assembly with cross-sections of 10 mm².
This pack consists of
- 2 x MC4 4mm² - 6mm² Male Cable Couplers.
- 2 x MC4 4mm² - 6mm² Female Cable Couplers.
Technical Specifications
- Rated current: 39A (4mm²,6mm²; 10AWG).
- System voltage max: 1000V (IEC/CEI) 600V (UL) Snap-in.
- Locking system: -40°C...+90°C (IEC/CEI).
- Temperature range: -40°C...+75°C (UL).
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
