Solis 6.0kW Dual MPPT 3-Phase Domestic Grid Tied Solar Kit

Solis 6.0kW Dual MPPT 3-Phase Domestic Grid Tied Solar Kit

Regular price R 87,567.00 incl. VAT
R 76,14522 excl. VAT
incl. VAT/
Please choose your roof mounting system here, if required.


Tax included. Shipping calculated at checkout.
  • Secure online payments

Solis 6.0kW Grid-tie Kit contains the following components

  • 20 x Renewsys Deserv 340W Solar Panel.
  • 1 x Solis 4G 6.0kW Dual MPPT 3-Phase Grid Tie Inverter.
  • 1 x K&N 32A Three Phase AC Switch Disconnector.
  • 3 x MC4 Pre terminated cable 2m (Pack of 2).
  • 1 x 600V Protection Box 2 Inputs 2 Outputs 16A Isolator Type I_II SPD.
  • 1 x Multi Contact Cable Coupler Pack - MC4.
  • 20m x Sustainable 6mm² Black Panelflex.
  • 20m x Sustainable 6mm² Red Panelflex.
  • 20m x Sustainable 6mm² Black Double Insulated Halogen Free Solar Cable.
  • 20m x Sustainable 6mm² Red Double Insulated Halogen Free Solar Cable.
  • 1 x Optional Roof Mounting System.

PV Performance Estimation
A. Installation Data - New MCS Calculation

  • Installed capacity of PV system - kWP (stc): 6.700 KWp.
  • Orientation of the PV system - degrees from South: 0°.
  • Inclination of system - degrees from horizontal: 35°.

B. Calculation

  • kWh/kWp (KK) from table1: 1,673 kWh/kWp.
  • Shade factor (SF): 1.00.
  • Estimated annual output (kWpxKKxSF): 10,204 kWh.

Important:

All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
