Onesto 80A 3kA 1P+N Earth Leakage
Specifications
- Protection: Ground Fault and Over current.
- Rated Current: 80A.
- Number of poles: 2(1+N).
- Rated Sensitivity: 30mA.
- Rated Voltages: 240Vac.
- Type of Trip: Electro-magnetic release.
- Type of terminal: Lug Type.
- Terminal Capacity: Cables up to 35mm.
- Installation: 35mm DIN Rail.
- Slot Size: 45mm.
- Dimensions: 36mm x 82mm x 72mm.
Important:
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
