- Safety: LFP(Lithium ion Phosphate) the highest safety.
- Up to 8 in Parallel: Flexible to increase capacity without any other equipment or settings.
- Cycle Life: ≥6000 cycles.
- Wi-Fi & APP: Integrated Wi-Fi Modem OTA online upgrade convenient after-sales service.
- Installation: Simple buckle fixing minimize the installation time and cost.
- High-precision SOC: Accurate sampling of voltage and current SOC mathematic more accurate and never jump.
- Module: FNB-5100S.
- Nominal Voltage (V): 51.2.
- Nominal Capacity (Wh): 5120.
- Usable Capacity (Wh): 4608.
- Dimension (mm): 442 x 500 x 133.
- Weight (Kg): 52.
- Voltage Range (V): 48 ~ 56.
- Charge/Discharge Current (A): 50/100 (Recommend).
- Communication Port: CAN / RS485.
- Single string quantity (pcs): 8.
- Working Temperature/°C (Charge): 0 ~ 45.
- Working Temperature/°C (Discharge): - 10 ~ 55.
- Storage Temperature/°C: - 20 ~ 60.
- Humidity: 5 ~ 85%.
- Altitude (m): <2000.
- IP Rating: IP20.
- Warranty: 10 Years.
- Cycle life: 6000.
- Authentication Level: UN38.3.
- Cooling Type: Ambient Cooling.
- Installation: Cabinet or Wall Mounting.
Weight: 40.5 kg (Only support paralleling configuration only).
All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. Sustainable Online will not be held liable for any product malfunctions as a result of incorrectly installed systems.
